Seamless Steel Line Pipe psl2 gr.x70 from China manufacturer - Cangzhou Qiancheng Steel-Pipe Co., Ltd.

Price:	800.0~1300.0 USD
Payment Terms:	T/T,L/C
Special Groups:	API High Grade Line pipes (84)
Place of Origin:	Hebei, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: API 5L PSL2 X70

Production Capacity: 5000 Ton/Month

Delivery Date: within 30-45 days after rec...

Type: Seamless/Welded(LSAW ERW SS...

WT: SCH10-SCH160 XXS(2.11-59.54...

Certificates: API Spec 5L,ISO 2001,LLyod'...

Barnd: QCCO

Means of Transport: Ocean,Land,Air

Packing: in bundles/in loose pieces;...

Name: STEEL LINE PIPE API 5L GRAD...

OD: 3/8"-36"(17.1-914.4mm)

Application: Conveying gas oil or water

Origin: Cangzhou,Hebei Prov.China

Cangzhou Qiancheng Steel-Pipe Co.,Ltd
Seamless/welded Carbon Steel Line Pipes API 5L PSL2 GRADE X70
Certificates:API SPEC 5L,ISO9001,Llyod's etc

Cangzhou Qiancheng Steel-Pipe Co.,Ltd

Seamless/welded Carbon Steel Line Pipes API 5L PSL2 GRADE X70

Mechanical Properties

Standard	Class	Grade	Min/Max	Yield strength (Mpa)	Tensile Strength (Mpa)	Elongation(%)	Y.S./T.S.(%)
API 5L	PSL1	L245B	min	245	415	b	-
		L290X42	min	290	415	b	-
		L320X46	min	320	435	b	-
		L360X52	min	360	460	b	-
		L390X56	min	390	490	b	-
		L415X60	min	415	520	b	-
		L450X65	min	450	535	b	-
		L485X70	min	485	570	b	-
	PSL2	L245B	min	245	415	b	0.93
		L245B	max	450	760	b	-
		L290X42	min	290	415	b	0.93
		L290X42	max	495	760	b	-
		L320X46	min	320	435	b	0.93
		L320X46	max	525	760	b	-
		L360X52	min	360	760	b	0.93
		L360X52	max	530	760	b	-
		L390X56	min	390	490	b	0.93
		L390X56	max	545	760	b	-
		L415X60	min	415	520	b	0.93
		L415X60	max	565	760	b	-
		L450X65	min	450	535	b	0.93
		L450X65	max	600	760	b	-
		L485X70	min	485	570	b	0.93
		L485X70	max	635	760	b	-
		L555X80	min	555	625	b	0.93
		L555X80	max	705	825	b	-

Chemical Composition

Standard	Class	Grade	C	Si	Mn	P	S	V	Nb	Ti
Standard	Class	Grade	max	max	max	max	max	max	max	max
API 5L	PSL1	L245 B	0.28	-	1.20	0.030	0.030	-	-	-
		L290 X42	0.28	-	1.30	0.030	0.030	-	-	-
		L320 X46	0.28	-	1.40	0.030	0.030	-	-	-
		L360 X52	0.28	-	1.40	0.030	0.030	-	-	-
		L390 X56	0.28	-	1.40	0.030	0.030	-	-	-
		L415 X60	0.28	-	1.40	0.030	0.030	-	-	-
		L450 X65	0.28	-	1.40	0.030	0.030	-	-	-
		L485 X70	0.28	-	1.40	0.030	0.030	-	-	-
	PSL2	L245N BN	0.24	0.40	1.20	0.025	0.015	-	-	0.04
		L290N X42N	0.24	0.40	1.20	0.025	0.015	0.06	0.05	0.04
		L320N X46N	0.24	0.40	1.40	0.025	0.015	0.07	0.05	0.04
		L360N X52N	0.24	0.40	1.40	0.025	0.015	0.10	0.05	0.04
		L390N X56N	0.24	0.40	1.40	0.025	0.015	0.10	0.05	0.04
		L415N X60N	0.24	0.40	1.40	0.025	0.015	0.10-	0.05	0.04

Type		Seamless/LSAW carbon steel line pipe
Executive Standard		API SPEC 5L,GB/T 9711.1,GB/T 9711.2,GB/T 9711.3,SY/T5037
Materials		PSL1—L245/L290/L320/L360/L390/L415/L450/L485 X42/X46/X52/X56/X60/X65/X70 PSL2—L245/L290/L320/L360/L390/L415/L450/L485 X42/X46/X52/X56/X60/X65/X70/X80
Size	Outer Diameter	Seamless 17-914mm 3/8-36 inch LSAW 457-1422mm 18-56 inch
	Wall Thickness	2-60mm SCH10 SCH20 SCH30 STD SCH40 SCH60 XS SCH80 SCH100 SCH120 SCH140 SCH160 XXS
	Length	Single random length/Double random length 5m-14m,5.8m,6m,10m-12m,12m or as customer's actual request
Ends		Plain end/Beveled,protected by plastic caps on both ends, cut quare,grooved,threaded and coupling,etc
Surface Treatment		Bare,Painting black,varnished,galvanized,anti-corrosion 3PE PP/EP/FBE coating
Technical Methods		Hot-rolled/Cold-drawn/Hot-expanded
Testing Methods		Eddy current testing, Hydrostatic testing or Ultrasonic examination, NDT and also with chemical and physical property inspection
Packaging		Small pipes in bundles with strong steel strips,large pieces in loose; Covered with plastic woven bags; Suitable for lifting operation; Loaded in 40ft or 20ft container or in bulk Also according to customer's requests
Application		Conveying oil gas and water
Origin		Hebei Prov.China
Certificates		API ISO PED Lloyd's (ISO 9001 in 2006,EU PED-97-23-EC in 2008,API 5L in 2009, CPD-93/68/EEC in 2011)
Third Party Inspection		SGS BV MTC
Trade Terms		FOB CIF CFR
Payment Terms		FOB 30%T/T,70% before shipment CIF 30% pre-payment and the balance to be paid upon B/L (copy) or Irrevocable 100% L/C at sight
MOQ		20 tons
Production Capacity		5000 T/M
Delivery Time		Usually within 30-45 days after receipt of advance payment

Main products: Seamless steel pipe

Line Pipe:API 5L(psl1,psl2)

Alloy-Steel Pipe for low temperature service: A333(GR.1 GR.3 GR.4 GR.6 GR.7...)

Boiler Pipe: A106 A210,DIN17175,GB 3087,GB 5310,JIS G 3461

Ferritic Alloy-Steel pipe for high temperature service:A335 (P1 P2 P5 P9 P11 P15 P22 P91...)

Fluid Tube: A53 A106, GB/T 8163, JIS G3454 3455 3456

Mechanical Tube: A519

Structural Tube: GB/T 8162(Q345B...) DIN1629

Tubing and Casing Pipe: API 5CT (J55,K55,N80,L80-1,P110...)

Tube for pipeline,pressure vessel: EN10216-1 EN10216-2

Seamless Circular Steel Tubes for mechanical and general engineering purpose: EN10297-1( alloy & non-alloy )

Hot-finished structural hollow sections of non-alloy and fine grain steels: EN 10210-1

Products we also supply

Stainless steel pipes

ERW LSAW SSAW steel pipe

Pipe Fittings: Bend Elbow Reducer Tee Cross Flange...

Company Advantages:

Best quality (original steel tubes from TPCO/Hengsteel(Hengyang valin)

/Shanghai Baosteel/Baotou Steel/Anshan...)

Large stock of various sizes and grades of steel pipes

Speedy delivery

Sample can be sent for testing

Customized design available

Small order acceptable
