Cangzhou Qiancheng Steel-Pipe Co., Ltd.
|
Gold Index: 138621
Price: | 650.0~900.0 USD |
Payment Terms: | T/T,L/C |
Special Groups: |
Line Pipe (226)
|
Place of Origin: | Hebei, China (Mainland) |
Add to My Favorites | |
HiSupplier Escrow |
Type | Seamless/LSAW carbon steel line pipe | |
ExecutiveStandard | API 5L | |
Materials | PSL1—L245B/L290X42/L320X46/L360X52/L390X56/L415X60/L450X65/L485X70 PSL2—L245/L290/L320/L360/L390/L415/L450/L485 X42/X46/X52/X56/X60/X65/X70/X80 | |
Size | Outer Diameter | Seamless:17-914mm 3/8"-36" LSAW 457-1422mm 18"-56" |
Wall Thickness | 2-60mm SCH10 SCH20 SCH30 STD SCH40 SCH60 XS SCH80 SCH100 SCH120 SCH140 SCH160 XXS | |
Length | Single random length/Double random length 5m-14m,5.8m,6m,10m-12m,12m or as customer's actual request | |
Ends | Plain end/Beveled,protected by plastic caps on both ends, cut quare,grooved,threaded and coupling,etc. | |
Surface Treatment | Bare,Painting black,varnished,galvanized,anti-corrosion 3PE PP/EP/FBE coating | |
Technical Methods | Hot-rolled/Cold-drawn/Hot-expanded | |
Testing Methods | Pressure test,Flaw detection,Eddy current testing, Hydrostatic testing or Ultrasonic examination and also with chemical and physical property inspection | |
Packaging | Small pipes in bundles with strong steel strips,large pieces in loose; Covered with plastic woven bags; Wooden cases;Suitable for lifting operation;Loaded in 20ft 40ft or 45ft container or in bulk; Also accrdin to customer's requests | |
Origin | Hebei Prov.China | |
Application | Conveying oil gas and water | |
Certificates | API ISO PED Lloyd's | |
Third Party Inspection | SGS BV MTC | |
Trade Terms | FOB CIF CFR | |
Payment Terms | FOB 30%T/T,70% before shipment CIF 30% pre-payment and the balance to be paid upon B/L (copy) or Irrevocable 100% L/C at sight | |
MOQ | 10 tons | |
Supply Capacity | 5000 T/M | |
Delivery Time | Usually within 30-45 days after receipt of advance payment |
Standard | Class | Grade | C | Si | Mn | P | S | V | Nb | Ti |
max | max | max | max | max | max | max | max | |||
API 5L | PSL1 | L245 B | 0.28 | - | 1.20 | 0.030 | 0.030 | - | - | - |
L290 X42 | 0.28 | - | 1.30 | 0.030 | 0.030 | - | - | - | ||
L320 X46 | 0.28 | - | 1.40 | 0.030 | 0.030 | - | - | - | ||
L360 X52 | 0.28 | - | 1.40 | 0.030 | 0.030 | - | - | - | ||
L390 X56 | 0.28 | - | 1.40 | 0.030 | 0.030 | - | - | - | ||
L415 X60 | 0.28 | - | 1.40 | 0.030 | 0.030 | - | - | - | ||
L450 X65 | 0.28 | - | 1.40 | 0.030 | 0.030 | - | - | - | ||
L485 X70 | 0.28 | - | 1.40 | 0.030 | 0.030 | - | - | - | ||
PSL2 | L245N BN | 0.24 | 0.40 | 1.20 | 0.025 | 0.015 | - | - | 0.04 | |
L290N X42N | 0.24 | 0.40 | 1.20 | 0.025 | 0.015 | 0.06 | 0.05 | 0.04 | ||
L320N X46N | 0.24 | 0.40 | 1.40 | 0.025 | 0.015 | 0.07 | 0.05 | 0.04 | ||
L360N X52N | 0.24 | 0.40 | 1.40 | 0.025 | 0.015 | 0.10 | 0.05 | 0.04 | ||
L390N X56N | 0.24 | 0.40 | 1.40 | 0.025 | 0.015 | 0.10 | 0.05 | 0.04 | ||
L415N X60N | 0.24 | 0.40 | 1.40 | 0.025 | 0.015 | 0.10- | 0.05 | 0.04 |
Standard | Class | Grade | Min/Max | Yield strength (Mpa) | Tensile Strength (Mpa) | Elongation(%) | Y.S./T.S.(%) |
API 5L | PSL1 | L245B | min | 245 | 415 | b | - |
L290X42 | min | 290 | 415 | b | - | ||
L320X46 | min | 320 | 435 | b | - | ||
L360X52 | min | 360 | 460 | b | - | ||
L390X56 | min | 390 | 490 | b | - | ||
L415X60 | min | 415 | 520 | b | - | ||
L450X65 | min | 450 | 535 | b | - | ||
L485X70 | min | 485 | 570 | b | - | ||
PSL2 | L245B | min | 245 | 415 | b | 0.93 | |
max | 450 | 760 | b | - | |||
L290X42 | min | 290 | 415 | b | 0.93 | ||
max | 495 | 760 | b | - | |||
L320X46 | min | 320 | 435 | b | 0.93 | ||
max | 525 | 760 | b | - | |||
L360X52 | min | 360 | 760 | b | 0.93 | ||
max | 530 | 760 | b | - | |||
L390X56 | min | 390 | 490 | b | 0.93 | ||
max | 545 | 760 | b | - | |||
L415X60 | min | 415 | 520 | b | 0.93 | ||
max | 565 | 760 | b | - | |||
L450X65 | min | 450 | 535 | b | 0.93 | ||
max | 600 | 760 | b | - | |||
L485X70 | min | 485 | 570 | b | 0.93 | ||
max | 635 | 760 | b | - | |||
L555X80 | min | 555 | 625 | b | 0.93 | ||
max | 705 | 825 | b | - |
